Short aluminium top end cap – Alliance
Références
SKU | Finishing stage | Pkg | Delay (d) |
---|---|---|---|
3ES92039 | 9005-30% | 100 | 14 |
3ES91039 | 9016-80% | 100 | 14 |
3ES92039RAL |
![]() |
1 | 14 |
Information
Commentaire
To screw-in
![Attention](https://www.tirard-burgaud.com/content/uploads/catalogue/ETI00000008en-picto-attention.png)
Attention
Fastening screws for short end caps to order separately:
-CBL TORX sheet metal screws – Ø4,8xL.32 mm – 304 stainless steel (please refer to the index).
-CBL TORX sheet metal screws – Ø4,8xL.32 mm – 304 stainless steel (please refer to the index).
![Astuce](https://www.tirard-burgaud.com/content/uploads/catalogue/ETI00000002en-picto-astuce.png)
Astuce
Tube length calculation:
tube length = total length of the Espagnolette bolt – 18 mm.
tube length = total length of the Espagnolette bolt – 18 mm.
